Double side ring shape led display, the outer ring used 40 column x 7 row 240mm x 120mm flexible led module, inner ring used 38column x 7 row 240mm x 120mm flexible led module. pixel pitch 2mm. total screen size:15.72sqm
Double side ring shape led display-4

Brief introduction of this project

Screen size:0.84m  in height, with 3m in diameter. The outer ring used 40 column x 7 row 240mm x 120mm flexible led module, inner ring used 38column x 7 row 240mm x 120mm flexible led module. total screen size:15.72sqm

Indoor fixed installation

Pixel pitch: 2mm

Brightness: 600nit for indoor use

Benfits of Flexible led screen

  1. Wide range of Pixel pitches from 1.25mm to 4mm
  2. Different module size choice, from 240x120mm, 320x160mm,  Can customized different size cabinet to suit different project needs
  3. Various installation ways, and also very easy to install, as the cabinet is very light.

Frame of the double size ring led screen

Double side ring shape led display

After attached led module on

Double side ring shape led display-3
